Messing around in sketchup

Post in 'The Boiler Room - Wood Boilers and Furnaces' started by chewy, Apr 10, 2013.

  1. chewy

    chewy
    Expand Collapse
    Member

    Joined:
    Nov 7, 2009
    Messages:
    134
    Likes Received:
    12
    Loc:
    Indiana
    Ok so I've been working with sketchup trying to wrap my head around how to plumb and install my gasser when I pull the trigger.

    What I think I'll do is build a boiler room where my "free heat machine" sits. I hope to be able to use my existing pex lines in the new setup. I will be using water to air heat exchangers in both buildings at first, and probably do some panel rads down the road.

    I'm really having a hard time figuring out where all of the pumps and valves and manifolds ect should go. I found an already designed piping diagram in 3d warehouse and even though I'd have to tweak it to fit my system, are all the parts on it there?

    My house heat loss calc came to 90kbtu and the shop 50kbtu. I have 4- 1" lines to the house and 4- 1" lines to the shop. The house run is 150' and shop is 30'. I will get 2 500 gal propane tanks for storage and its my understanding that these tanks should go vertical? 1.25" pipe in and out of each tank top and bottom? Oversize or undersized the gasser?

    Its like kicking a dead horse with me!
    Ty in advance

    Erin


    Attached Files:

    Collapse Signature Expand Signature

    Helpful Sponsor Ads!





  2. WmFritz

    WmFritz
    Expand Collapse
    Member

    Joined:
    Dec 5, 2012
    Messages:
    10
    Likes Received:
    1
    Loc:
    Northern Lower Michigan
    Looks like your on your way. I know for me, I need something visual to go by.
    How big is your boiler room?

  3. chewy

    chewy
    Expand Collapse
    Member

    Joined:
    Nov 7, 2009
    Messages:
    134
    Likes Received:
    12
    Loc:
    Indiana
    12'x18' in the pic, but ill probably go a little bigger bc It's filling up fast.

    Erin

    Collapse Signature Expand Signature
  4. Coal Reaper

    Coal Reaper
    Expand Collapse
    Minister of Fire

    Joined:
    Aug 10, 2012
    Messages:
    775
    Likes Received:
    250
    Loc:
    NJ
    i think yer gonna need a bigger expansion tank...
    yes to vertical tanks if you can make it happen. i did 1-1/4" copper from boiler to tanks and 1-1/4" PEX from tanks to house. with storage, the size of the boiler will dictate how long it takes to charge the tanks and how many times you will need to reload.

    Collapse Signature Expand Signature
  5. maple1

    maple1
    Expand Collapse
    Minister of Fire

    Joined:
    Sep 15, 2011
    Messages:
    6,443
    Likes Received:
    1,117
    Loc:
    Nova Scotia
    Vertical if you have room for that. Or you can stack them horizontally if you don't have the room. Either way, get your tappings as close to the top & bottom as possible.

    Collapse Signature Expand Signature
  6. Coal Reaper

    Coal Reaper
    Expand Collapse
    Minister of Fire

    Joined:
    Aug 10, 2012
    Messages:
    775
    Likes Received:
    250
    Loc:
    NJ
    Collapse Signature Expand Signature
  7. maple1

    maple1
    Expand Collapse
    Minister of Fire

    Joined:
    Sep 15, 2011
    Messages:
    6,443
    Likes Received:
    1,117
    Loc:
    Nova Scotia
    I also used a Wye - likely should be considered essential, even though they have a fairly coarse mesh in them. For sediment collection purposes, I have one end of my horizontal tanks just a little higher than the other. Maybe a half inch? That end has the bottom outlet tapping. The other end has a small tapping for a drain valve - I don't really plan on any regular drainings though. The connection between top & bottom tanks is at the low end, so anything that comes out of the top tank & into the bottom tank should settle in the bottom tank at the low end. My tanks were fairly clean so I should be OK for dirt. All that also puts the top outlet tapping at the high point so I should always be drawing off the hottest water possible from storage too.

    Collapse Signature Expand Signature
  8. chewy

    chewy
    Expand Collapse
    Member

    Joined:
    Nov 7, 2009
    Messages:
    134
    Likes Received:
    12
    Loc:
    Indiana
    Can anyone create a list of items that is needed to do any gasser install?
    I want to start watching Craigslist and ebay for boiler stuff.
    Here's what I came up with

    Water temp valve
    Pump
    Manifolds
    Expansion tank

    Erin

    Collapse Signature Expand Signature
  9. Coal Reaper

    Coal Reaper
    Expand Collapse
    Minister of Fire

    Joined:
    Aug 10, 2012
    Messages:
    775
    Likes Received:
    250
    Loc:
    NJ
    if you PM me your email address i can send you an excel sheet of most of the items i used
