Replacing the old Pull Chain light for a new drop ceiling is Plug & Play

Post in 'DIY and General non-hearth advice' started by Don2222, Apr 22, 2014.

  1. Don2222

    Don2222 Minister of Fire

    Joined:
    Feb 1, 2010
    Messages:
    7,047
    Loc:
    Salem NH
    Hello

    The old pull chain does not cut the mustard with the new drop ceiling. Just removed the old pull chain socket, Mark the wires with a black marking pen, put in a wall switch and just did a lil lectrical and pluged in the new one. The light panel can be moved to a different square very easily too.

    Has anyone else done something like this?
    How did you do it?

    Pic1 - Old Pull Chain
    Pic2 - Drop ceiling pane with pancake electrical box
    Pic3 - New workbox and outlet
    Pic4 - Twist, solder and duct tape wires
    Pic5 - Plug in Panel
    Pic6 - screw in bulbs
    Pic 7&8 - It works and looks good!

    Attached Files:

    Last edited: Apr 22, 2014

    Helpful Sponsor Ads!





  2. AK13

    AK13 Member

    Joined:
    Oct 15, 2010
    Messages:
    191
    Loc:
    Seacoast, NH
    Nice install! I've never used solder before on home wiring. I just twist and use wire nuts.
  3. Don2222

    Don2222 Minister of Fire

    Joined:
    Feb 1, 2010
    Messages:
    7,047
    Loc:
    Salem NH
    This was a tight area so used the solder.
    I usually use the Scotch Locks, they work the best!
    [​IMG]
  4. bassJAM

    bassJAM Feeling the Heat

    Joined:
    Jun 5, 2012
    Messages:
    363
    Loc:
    Cincinnati OH
    I can't tell if you used wire nuts, or just soldered and covered the connections with duct tape. If that's the case, I'd highly recommend pulling off the duct tape and using electrical tape. I don't think duct tape has near the insulating property of electrical tape.
  5. begreen

    begreen Mooderator Staff Member

    Joined:
    Nov 18, 2005
    Messages:
    47,102
    Loc:
    South Puget Sound, WA
    The main mistake made here (and mentioned before) is that the wires are stripped too short. In the box each wire should be at least 6" long. This makes future work so much easier. And in the fixture, well that is just plain wrong. Duct tape, short connection, no wire nuts, what could possibly go wrong? That duct tape will be dust in a few years. I'd do it over.
  6. heat seeker

    heat seeker Minister of Fire

    Joined:
    Feb 25, 2011
    Messages:
    1,949
    Loc:
    Northern CT
    Agreed - lose the duct tape ASAP!
  7. Don2222

    Don2222 Minister of Fire

    Joined:
    Feb 1, 2010
    Messages:
    7,047
    Loc:
    Salem NH
    Thanks for keeping me on track. I will find 2 more wire nuts and loose the duct tape.
    Warm_in_NH likes this.
  8. fossil

    fossil Accidental Moderator Staff Member

    Joined:
    Sep 30, 2007
    Messages:
    10,185
    Loc:
    Bend, OR
    If you're gonna post pics and detailed descriptions of your DIY projects, please take the time first to make sure that what you're showing off about has been done correctly, professionally, and in accordance with applicable code requirements such that it would pass an inspection. What you've shown us here doesn't measure up, and we're not interested in passing along bad ideas on these forums. Thanks, Rick
  9. velvetfoot

    velvetfoot Minister of Fire

    Joined:
    Dec 5, 2005
    Messages:
    6,543
    Loc:
    Sand Lake, NY
    That's kind of harsh. He's opening himself up to critique and is correcting things based on it. The end result for him is a positive and the process is a learning experience for anyone reading the thread.
    bassJAM, Grisu, Don2222 and 1 other person like this.
  10. fossil

    fossil Accidental Moderator Staff Member

    Joined:
    Sep 30, 2007
    Messages:
    10,185
    Loc:
    Bend, OR
    I'm sorry.
  11. velvetfoot

    velvetfoot Minister of Fire

    Joined:
    Dec 5, 2005
    Messages:
    6,543
    Loc:
    Sand Lake, NY
    Sorry if I sounded harsh. :)
  12. seige101

    seige101 Minister of Fire

    Joined:
    Mar 25, 2008
    Messages:
    530
    Loc:
    Palmer, MA
    There are a bunch of code violations there i will address a couple of them and give you some suggestions to make it right.

    Plugs above a drop ceiling are illegal along with using that appliance whip to convert a hard wired fixture to plug in base.

    That box is not proper for the application nor is the support.

    This nifty box snaps right onto the t-grid. The box must have a tie wire from the box to the structure (floor joist in your case) in case the ceiling gets wet or a fire the fixture will stay suspended and not be a hazard to you or fire fighters.

    As others have said, soldering connections is a big no no and is not kosher to do now a days. If a fault condition occurs (the wires or fixture or bulb shorts out) the intense current flow will blow the connection apart. Put some of those nice wire nuts you pictured on there and you will have a nice solid mechanical and electrical connection. Duct tape is not an insulator, and electrical tape is not a proper connection. Those wires could be touching your metal box and from minute vibrations the copper will wear through the tape and eventually short out.

    There should only be 1/4" max of the romex sheath in your 4" box and a staple within 6" of the romex where it enters the connector.

    I want to make sure you have a safe install! If you have any questions please ask

    /Electrician is the day job
  13. Don2222

    Don2222 Minister of Fire

    Joined:
    Feb 1, 2010
    Messages:
    7,047
    Loc:
    Salem NH
    Thanks for showing the T-Grid light work box, I never knew they made one for that. :)
  14. yooperdave

    yooperdave Minister of Fire

    Joined:
    Oct 26, 2010
    Messages:
    1,128
    Loc:
    Michigan's U.P.
    Don, I think we may have you straightened out on the electrical projects now???

    Next, we'll move on to burning wood, not pellets!
  15. Don2222

    Don2222 Minister of Fire

    Joined:
    Feb 1, 2010
    Messages:
    7,047
    Loc:
    Salem NH
    Thanks Dave

    You know I had a Franklin and then a VC Consolidated DutchWest Federal Design Large Wood/Coal Stove model # FA288CCL (Pre90) with the catalytic combustor for 19 years, but even with typical stove temps from the top mounted thermometer were 800 to 1000 deg F, I was not happy with the heat output. The convection fan was mounted in the back and may have been an add on design because it never seemed to work that well. Do you think a better wood stove like a BK or something like that would be better?

    I do like the P61 updated to a P61a-2 better than the Astoria because it radiates heat very well, just like a wood stove! LOL Also notice in the background the old Valiant oil boiler with tankless coil was upgraded to the triple pass,cold start Buderus boiler with the outdoor reset and SuperStor DHW. :)
    See pics

    Attached Files:

    Last edited: Apr 23, 2014
