Huskee 22 ton splitter - detent problem

[wood_man]

Hello all, I need some help please. I 'tried' to adust the detent as my return was not stopping as quick as I would like. I took the cap off, removed the large bearing and found the slotted top. It was not turning at all. After applying a decent amount of force to it, I decided it wasnt worth screwing something up so I stopped. One thing I did do was I pulled up the outer sleave,, and yes to my surprise 4 little bearings popped out. Good news is I was able to find all four, whew
My problem now is,,, I put the spring back, then the 4 bearing, the sleave (with the 2 grooves at the bottom) then the large bearing,,,

It wont work,,,, the cylinder is all the way out,, it wont retract. What am I doing wrong please??



[wood_man]

Hello all, I need some help please. I 'tried' to adust the detent as my return was not stopping as quick as I would like. I took the cap off, removed the large bearing and found the slotted top. It was not turning at all. After applying a decent amount of force to it, I decided it wasnt worth screwing something up so I stopped. One thing I did do was I pulled up the outer sleave,, and yes to my surprise 4 little bearings popped out. Good news is I was able to find all four, whew
My problem now is,,, I put the spring back, then the 4 bearing, the sleave (with the 2 grooves at the bottom) then the large bearing,,,

It wont work,,,, the cylinder is all the way out,, it wont retract. What am I doing wrong please??

Quick update.. if I take the bearings out, it will retract . With the bearings in place, the level itself cannot go all the way back, therefore the cylinder isn’t triggered to go retract.



[brenndatomu]

How to fix the automatic return on a log splitter - Offgridmaker.com

Learn how to adjust or repair the auto return on your log splitter. This is an easy step by step how-to with pictures.

offgridmaker.com

(BR004117DA) Energy Valve Detent Assembly (S39044300)

Discover this replacement energy valve detent assembly (BR004117DA), available online from Foards Parts Plus. We have a large selection of parts for sale.

www.foards.com

Energy Log Splitter Valve: 20 GPM, 1/2" Work Ports, Auto Return Detent

This Energy valve replaces the OEM valve on many popular hydraulic log splitters from Speeco, Brave, Dirty Hand Tools, Huskee, County Line, Yardmax, MTD, Northern Tool, and others. 20 GPM flow rate Auto return detent Single spool 2,500 PSI pressure rating 2,000 PSI relief valve (adjustable) 750...

ruggedmade.com

Log Splitter Valve: 30 GPM, 1/2" Work Ports, Auto Return Detent

This RuggedMade hydraulic directional control valve is suitable for a wide range of applications, including log splitters. 30 GPM flow rate Auto return detent Single spool 3,500 PSI pressure rating 2,250 PSI relief valve setting (adjustable) 800 PSI detent release pressure (non-adjustable) 1/2"...

ruggedmade.com



[wood_man]

Quick update.. if I take the bearings out, it will retract . With the bearings in place, the level itself cannot go all the way back, therefore the cylinder isn’t triggered to go retract.

Excellent - thank you very much! It ended up being the large ball bearing needs to go between the spring and the 4 ball bearings, not on top of the 4 bearings. Rookie error but thats something I wont every forget now!!

Thanks again!!



[oilstinks]

Just done this and greased it all as it was very rough. I was racking my brain to remember.
