Homesteaders on youtube with chimney through wood paneling

[St. Coemgen]

Is that what I think it is in the background -- a stove chimney pipe right through the wood paneling? I thought even insulated pipe has appropriate distances and proper fittings to go through a wood paneling like that. Or am I wrong and missing something?

To view this content we will need your consent to set third party cookies.
For more detailed information, see our cookies page.

Accept third party cookies



[RandyBoBandy]

This stuff cracks me up. If you are a "home steader" attempting to live "off the grid" and live a life secluded from the rest of the modern world then why are you making 20 minute videos using electronics and posting these videos on social media type websites for the world to see?



[RandyBoBandy]

And yes I sure does look like the stove pipe goes right through the wood paneling.



[Ctwoodtick]

Is that what I think it is in the background -- a stove chimney pipe right through the wood paneling? I thought even insulated pipe has appropriate distances and proper fittings to go through a wood paneling like that. Or am I wrong and missing something?

To view this content we will need your consent to set third party cookies.
For more detailed information, see our cookies page.

Accept third party cookies

For piece of mind, I’d send them a comment through their video with your concerns. Seems like a reasonable thing to do.



[Simonkenton]

They will be plenty warm for a couple of hours, on the day their house burns down.



[webby3650]

I’ve seen lots of no clearance installs that have been in use for 20 or more year with no problems. Unfortunately, there’s no “symptoms” of a problem in this instance. One day, the house is on fire! Not much can be done then...



[kennyp2339]

I’ve seen lots of no clearance installs that have been in use for 20 or more year with no problems. Unfortunately, there’s no “symptoms” of a problem in this instance. One day, the house is on fire! Not much can be done then...

I agree, even with class a metal pipe under normal burning conditions the outside of the pipe just gets warm to the touch, so you may not have any issues for 20 years, but bam, just like that you have a chimney fire and the inside of the pipe which is normally 450 - 600 deg runs up to 1800 deg from burning creosote and now the outside pipe is 800 deg and through conduction the combustibles nearby catch.
The other day I went on a legit chimney fire call, the setup was within all clearances, 8" single wall to class a through the wall and then up the outside of the house, that class a outside was red hot to the touch and discolored slightly at the 30 deg elbow where the creosote was burning, nothing happened to the house though because all the required clearances were met.



[armanidog]

I watched some of their videos. They built a rocket mass heater. the fire is exhausted into a barrel, then through 20 feet of stove pipe embedded in a mass of rock and clay/sand mixture, and then up the chimney. I guess they figured that since the fire is only lit for four hours with small splits and the exhaust is circulated through the barrel and stove pipe that the temps will be safe. He did say he used a class A double wall chimney and chimney box.
But like kennyp2339 said, that wood ceiling could be heated up by creosote burning in the system. I left a comment.



[Woody5506]

This stuff cracks me up. If you are a "home steader" attempting to live "off the grid" and live a life secluded from the rest of the modern world then why are you making 20 minute videos using electronics and posting these videos on social media type websites for the world to see?

Because they are hipsters.



[RandyBoBandy]

Because they are hipsters.

You mean these people?



[edyit]

they said It's not a chimney It's the center of the steel spiral staircase.



[St. Coemgen]

they said It's not a chimney It's the center of the steel spiral staircase.

Hm. If they say so. But then that is then the thickest spiral staircase post in existence.

And spiral staircase posts do not need to go into the ceiling like that.



[yooper08]

Doesn't really look like a flue to me. Looks more rectangular than anything else, perhaps slightly oval.



[begreen]

Hm. If they say so. But then that is then the thickest spiral staircase post in existence.

And spiral staircase posts do not need to go into the ceiling like that.

Stairway to Heaven?



[begreen]

Looking at their other videos I can see that there is a center spiral staircase with a big black center pipe. Perhaps it's anchored to the roof rafters above the ceiling wood paneling.

It sounds like the option is to heat the place with hot water radiant floors in the future, but now they heat with a rocket stove. Staircase build starts around 10:55. Rocket mass heater starts at 14:00 but no details on chimney. They typically fire the rocket heater at night, once a day.

To view this content we will need your consent to set third party cookies.
For more detailed information, see our cookies page.

Accept third party cookies



[yooper08]

Ah, I guess it is circular. Also, I think the rocket stove is on the right side of the frame in the first post, there's something on the very edge of the frame, and the staircase is on the left. See begreen's video starting at 16:40.
