Stove top ovens?

[BrianK]

I've often searched the internet for ovens that can be placed on top of our wood stoves for baking. The two most common I've found are the Coleman folding camp ovens (I've got one but never tried it) and the (broken link removed to https://www.lehmans.com/p-2632-fullsize-perfection-oven.aspx) in Ohio.

I just stumbled upon a new modular oven made from high density cast refractory. I don't see a price yet but this unit looks promising:

(broken link removed to http://blog.dragonheaters.com/outdoor-kitchen-the-oven-part-2/#comment-347)
September 5, 2013 by (broken link removed to http://blog.dragonheaters.com/author/smathieu/) (broken link removed to http://blog.dragonheaters.com/outdoor-kitchen-the-oven-part-2/#comments)
(broken link removed to http://blog.dragonheaters.com/wp-content/uploads/2013/09/Ovencropmed.jpg)

Here is the oven that we will use in our outdoor kitchen. As you can see it assembles in less than 90 seconds, yet ships flat. The joints will of course be filled with clay mortar when it is installed. Here is a quick video of its assembly.

The groves are for adjustable shelves. The interior is 12×12.

(broken link removed to http://blog.dragonheaters.com/wp-content/uploads/2013/09/OvenInterior.jpg)

To view this content we will need your consent to set third party cookies.
For more detailed information, see our cookies page.

Accept third party cookies



[pen]

I have an old one that we used to use on a kalamazoo cook stove that I keep threatening to modify to work atop my 30.

Never seen one like you mentioned. Wonder how quickly it heats up compared to the light metal ones

pen



[EatenByLimestone]

I was given one of the old Coleman ones. I've never had it out of the box.



[BrianK]

I have an old one that we used to use on a kalamazoo cook stove that I keep threatening to modify to work atop my 30.

Never seen one like you mentioned. Wonder how quickly it heats up compared to the light metal ones

pen

I'd imagine it takes a while to heat up. They are building this oven as part of a rocket stove outdoor kitchen and it looks like they are placing it inside one of the "bells" of the rocket heater, not over the riser (which in this illustration is covered by a cast iron cook top):

(broken image removed)



[begreen]

Where does that dragon heater vent? Is the exhaust routed around the oven?



[BrianK]

Where does that dragon heater vent? Is the exhaust routed around the oven?

Yes but apparently they vent down low to the ground. The heat rises and fills the "bell" as in a masonry wood stove and the exhaust is taken off from the bottom of the bell to let the heat rise and stay in the bell. They explain it here:
(broken link removed to http://www.dragonheaters.com/castle-build-masonry-heater-exhaust-flow/)
And here:
(broken link removed to http://blog.dragonheaters.com/wood-heat-storage-flues-vs-bells/)



[coaly]

Griswold made them in different sizes. One with glass front was called the BOLO, stands for Big Oven / Little Oven. They are a good size with two racks. We use them as a bread box and pie safe while not in use. 20" wide, 14" deep, 18" high.



[BrianK]

Griswold made them in different sizes. One with glass front was called the BOLO, stands for Big Oven / Little Oven. They are a good size with two racks. We use them as a bread box and pie safe while not in use. 20" wide, 14" deep, 18" high.
View attachment 111046 View attachment 111047

That's a well designed and nicely sized unit. Hard to find one at a reasonable price, judging by a quick search.



[DevilsBrew]

Have they posted a price for the oven? Can you buy a cast oven separately on the internet?



[BrianK]

Have they posted a price for the oven? Can you buy a cast oven separately on the internet?

I sent them an email and they said they will be selling the oven as a stand alone accessory. They are also developing a door for it. I have not received any info on pricing.



[DevilsBrew]

What type of door do you use on an outdoor oven? I have only seen people rig metal sheets on youtube.



[BrianK]

What type of door do you use on an outdoor oven? I have only seen people rig metal sheets on youtube.

I'm not sure. I asked about using it on top of a wood stove. Here is their response:

Yes it is available for separate purchase. Do you need a door? We are working on a door.

The oven currently has tabs at the back for resting on a flue. You may not want the tabs if you are just going to set it on top of a stove.



[Jags]

Coaly - you got any guess to the vintage of those Griswold stoves? They are pretty darn cool.



[coaly]

Old thread, but the ultimate stove top oven sold on eBay for $200 and I've never seen one like it. AFTER it sold I found they retailed for $300 when made, probably should have gone for it. Stainless Steel, no longer made, by Pacific Energy.



Even a strap on the back to connect to stove pipe.

Looking at this design, and price, I'm tempted to pick up an old toaster oven, (OK, on trash day) remove the electrics and bottom and make a stainless baffle with holes for the bottom. Glass door is the most important so it doesn't need to be opened while baking.

Coaly - you got any guess to the vintage of those Griswold stoves? They are pretty darn cool.

Here's some ads I came across from 1924 for the Griswold BO-LO. I never knew what was meant by big or little oven, and found my "Flue Plate" that I never knew existed was slid in at the very top like an oven rack. I thought it was the oven top inside. It's a double wall plate that you slide into the rack where you want to make the oven smaller. So it heats a smaller area quicker on the bottom when not so much room is needed. An adjustable roof inside. It heats much faster when only heating the area you need instead of waiting for the entire area to heat.

Plates shown removed on left.



So when I slid the false top out of the oven, the directions are stamped into the flue plate!

Without it, the heat radiates through the single wall oven top and doesn't heat. EDIT ; So measuring from the bottom rack, I can make the heated area 6 inches, or 10 inches high. It will get a lot more use knowing it heats much faster when set right. Duh.........



[rideau]

You can use any closed pot or roaster as an oven. I do all the time. You can set it directly on the cooktop or soapstone if you have the item you are baking elevated in the "oven", or you can set an oven rack over the stove and set the "oven" directly on the rack with the item being baked sitting on the bottom of the "oven" (no internal rack). Advantage: you don't need any more "tools" around the house.

That Griswold looks fine.



[coaly]

We have two stove top ovens used as a bread box and pie safe when not in use.
The manufacturer of that oven states "not for use with soapstone". That's why it was sold on eBay. It wouldn't bake without removing the bottom shield and cooking on stove top. The seller said cookies had to be finished by removing bottom shield and finishing on stove top.
The only time my wife uses the extra ovens is when the cook stove oven is full. The stove top is in the 600 range when oven is on anyway. Some cakes don't do well opening a door or changing temperature to check them.
So we're way beyond a cover or roaster. The reason it's nice to double bake on top as well is the temperature rise in the house while baking. If you're going to bring it up to temp in the summer, you do it all at once. The PE oven holds 4 loaves, the Griswold 8. For pizza, these don't get near as hot as the cook stove oven.
Last week the electric toaster got bumped for a stainless stove top toaster ! These things are more than an electric one!
